SD25TxxxL100, T1+T2

Uc: 150 … 680 VAC
Iimp (10/350 μs): 5 … 12.5 kA
In (8/20μs): 25 kA
Imax (8/20μs): 40 kA
Protection Mode: 1P (Ld – Ld)

Download PDF
